![[CLC-120-UVAR-F12] Collection lens for high vacuum](https://inteleg.io/264-pd4_def/-clc-120-uvar-f12-collection-lens-for-high-vacuum.jpg "[CLC-120-UVAR-F12] Collection lens for high vacuum")
keyboard_arrow_rightkeyboard_arrow_left
[CLC-120-UVAR-F12] Collection lens for high vacuum
Rugged, high-vacuum compatible, UV-VIS-NIR range lens for harsh process environment
- Security policy
- Delivery policy
- General Terms and Conditions
- Warranty
- MPN
- CLC-120-UVAR-F12
- Brand
- Inteleg
- Form-Fit-Function Equivalents
- -
- Warranty
- -
Material : stainless steel
Lens diameter : 12 mm
Lens material : UVFS + UVAR
Temperature : 250 deg. C
Vacuum use : high-vacuum EFL : 12 mm
Wavelength range : 250 - 425 nm
Interface 1 : 3/4-16 external thread
Interface 2 : SMA905
Focus : Adjustable
RoHS Compliant: Yes
Lens diameter : 12 mm
Lens material : UVFS + UVAR
Temperature : 250 deg. C
Vacuum use : high-vacuum EFL : 12 mm
Wavelength range : 250 - 425 nm
Interface 1 : 3/4-16 external thread
Interface 2 : SMA905
Focus : Adjustable
RoHS Compliant: Yes
